Af-Tor

Game infos

Sound infos

Driver infos

Inputs infos

Dipswitchs

• 2x multi during multiball
  • Off
  • On
• Balls
  • 2
  • 3
  • 4
  • 5
• Capture ball in multiball
  • Off
  • On
• Chute 1
  • 1 Coin/1 Credit
  • 1 Coin/2 Credits
  • 1 Coin/3 Credits
  • 1 Coin/4 Credits
  • 1 Coin/5 Credits
  • 1 Coin/6 Credits
  • 1 Coin/7 Credits
  • 1 coin 1 credit up to 3, then 4th coin gives 2 credits
  • 1 coin 1 credit, next coin gives 2 credits
  • 1 coin 10 credits
  • 1 coin 14 credits
  • 1st coin 1 credit, 2nd coin 2 more credits, 3rd coin 1 credit, 4th coin 3 more credits
  • 2 Coins/1 Credit
  • 2 Coins/5 Credits
  • 2 Coins/7 Credits
  • 2 coins 1 credit then 2 coins for 2 more credits
• Chute 2
  • 1 Coin/1 Credit
  • 1 Coin/2 Credits
  • 1 Coin/3 Credits
  • 1 Coin/4 Credits
  • 1 Coin/5 Credits
  • 1 Coin/6 Credits
  • 1 Coin/7 Credits
  • 1 coin 1 credit up to 3, then 4th coin gives 2 credits
  • 1 coin 1 credit, next coin gives 2 credits
  • 1 coin 10 credits
  • 1 coin 14 credits
  • 1st coin 1 credit, 2nd coin 2 more credits, 3rd coin 1 credit, 4th coin 3 more credits
  • 2 Coins/1 Credit
  • 2 Coins/5 Credits
  • 2 Coins/7 Credits
  • 2 coins 1 credit then 2 coins for 2 more credits
• Credits for new High score
  • 0
  • 1
  • 2
  • 3
• Disable Credits display
  • Off
  • On
• Disable Match display
  • Off
  • On
• Drain eject hole on outhole
  • Off
  • On
• Extra ball allowed
  • Off
  • On
• Fast Ride Lights Extra Ball
  • 2
  • 3
• Flip special lights
  • Alternate
  • Both on
• Free Play
  • Off
  • On
• Level pass payout
  • Extra Ball
  • Free Game
• Maximum credits
  • 10
  • 15
  • 25
  • 40
• One extra ball per ball
  • Off
  • On
• Release Targets Spot Wico
  • Off
  • On
• Reset left outlane gate
  • Off
  • On
• Saves multi-lights
  • Off
  • On
• Saving Top Lane Lights
  • Off
  • On
• Special bonus
  • 100k points
  • Extra Ball
  • Free Game
  • Nothing

Roms list

console	name	bios	size	crc	md5	merge	sha1	region	offset	status	optional
arcade	u25.bin		4096	d66e95ff			f7e8c51f1b37e7ef560406f1968c12a2043646c5	hcpu	f000	good	no
arcade	u48.bin		8192	b4406563			6d1a9086eb1f6f947eae3a92ccf7a9b7375d85d3	ccpu	e000	good	no
arcade	u52.bin		8192	8035b446			3ec59015e259c315bf09f4e2046f9d98e2d7a732	ccpu	8000	good	no

Chips list

name	tag	type	clock
M6809	hcpu	cpu	1250000
SN76494	sn76494	audio	156250
Samples	samples	audio
Speaker	mono	audio

Samples list

name
bumper
chime1
chime2
chime3
chime4
coil_coinlockout_engage
coil_coinlockout_release
coinin
drop_target_reset
hole
kickback
knocker
outhole
relay_engage
relay_release
sling
solenoid_engage
solenoid_release

Categories

• Added to Mame in version .141u1
• Electromechanical
• Pinball

MAMEinfo

0.141u1 [PinMAME]


Samples required (genpin)


WIP:

- 0.155: Minor Af-Tor cleanups and notes. Minor improvements. Added missing inputs and mechanical sounds. Added notes. Fixed broken bank of switches [Robbbert].

- 0.148u2: Robbbert fixed M6809 regression (slow sound) in Af-Tor.

- 0.147u2: Converted Wico/Af-tor pinball system to derived classes. Small cleanup [Robbbert]. Added 2nd mono Speaker.

- 0.147u1: Af-Tor WIP (Schematic and PinMAME used as references). Fixed display, marked as WORKING [Robbbert]. Added SN76494 (156250 Hz) sound, Samples (bumper, chime1, chime2, chime3, coinin, hole and knocker.wav) and mono Speaker. Added Player 1, 2x coin slots and dipswitches.

- 0.147: Various preliminary Pinball works [Robbbert]. Added M6809 (1250000 Hz) CPU2.

- 0.141u1: Added 'Af-Tor' (Wico 1984).
