Vs. Janshi Brandnew Stars

Game infos

Parent and clones

Sound infos

Driver infos

Inputs infos

Controls infos

type	ways	minimum	maximum	sensitivity	keydelta	reverse
mahjong						no

Display infos

type	rotate	flipx	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart
raster	0	no	320	224	60
raster	0	no	320	224	60

Dipswitchs

• Coinage
  • 1 Coin/1 Credit
  • 1 Coin/2 Credits
  • 1 Coin/3 Credits
  • 1 Coin/4 Credits
  • 2 Coins/1 Credit
  • 3 Coins/1 Credit
  • 4 Coins/1 Credit
  • 5 Coins/1 Credit
• Demo Sounds
  • Off
  • On
• Difficulty
  • Easier
  • Easiest
  • Easy
  • Hard
  • Harder
  • Hardest
  • Normal
  • Very Easy
• First Point
  • 10000
  • 15000
  • 20000
  • 23000
  • 25000
  • 26000
  • 30000
  • 5000
• Free Play
  • Off
  • On
• Taisen Only
  • Off
  • On
• Test Mode
  • Off
  • On
• Tumo Pinfu
  • Off
  • On
• Unused
  • Off
  • On

Roms list

console	name	bios	size	crc	md5	merge	sha1	region	offset	status	optional
arcade	mb-93142.36		524288	2eb6a503			27c02ab1b4321924fd4499844467ea4dc97de25d	maincpu	3	good	no
arcade	mb-93142.37		524288	49f60882			2ff5b0989aaf970103304a453773e0b9517ebb8d	maincpu	2	good	no
arcade	mb-93142.38		524288	6e1312cd			4c22f8f9f1574eefd96147453cf240f50c17f5dc	maincpu	1	good	no
arcade	mb-93142.39		524288	56b98539			5eb0e77729b31e6a100c1b43813a39fea57bedee	maincpu	0	good	no
arcade	mr96004-01.20		2097152	3366d104			2de0cabe2ead777b5b02cade7f2003ef7f90b75b	gfx1	0	good	no
arcade	mr96004-02.28		2097152	ad556664			4b36f8d8d9efa37cf515af41d14433e7eafa27a2	gfx1	2	good	no
arcade	mr96004-03.21		2097152	b399e2b1			9b6a00a219db8d66dcf592160b7b5f7a86b8f0c9	gfx1	400000	good	no
arcade	mr96004-04.29		2097152	f4f4cf4a			fe497989cf96c68602f68f14920aed44fd934573	gfx1	400002	good	no
arcade	mr96004-05.22		2097152	cd6c357e			44cd2d0607c7ccd80f701cf1675fd283acb07252	gfx1	800000	good	no
arcade	mr96004-06.30		2097152	fc6daad7			99f14ac6b06ad9a8a3d2e9f69b693c7ce420a47d	gfx1	800002	good	no
arcade	mr96004-07.23		2097152	177e32fa			3ca1f397dc28f1fa3a4136705b92c63e4e438f05	gfx1	c00000	good	no
arcade	mr96004-08.31		2097152	f6df27b2			60590976020d86bdccd4eaf57b349ea31bec6830	gfx1	c00002	good	no
arcade	mr96004-09.1		4194304	7f8ea9f0			f1fe682dcb884f1aa4a5536e17ab94157a99f519	gfx2	0	good	no
arcade	mr96004-09.7		4194304	7f8ea9f0			f1fe682dcb884f1aa4a5536e17ab94157a99f519	gfx3	0	good	no
arcade	mr96004-10.1		4194304	83f4303a			90ee010591afe1d35744925ef0e8d9a7e2ef3378	ymf2	0	good	no
arcade	mr96004-11.11		2097152	e6da552c			69a5af3015883793c7d1343243ccae23db9ef77c	gfx4	0	good	no
arcade	mr96004-11.13		2097152	e6da552c			69a5af3015883793c7d1343243ccae23db9ef77c	gfx6	0	good	no
arcade	sb93145.5		262144	0424e899			fbcdebfa3d5f52b10cf30f7e416f5f53994e4d55	audiocpu	0	good	no
arcade	vsjanshi5.6		524288	fdbbac21			c77d852e53126cc8ebfe1e79d1134e42b54d1aab	gfx7	0	good	no
arcade	vsjanshi6.5		524288	fdbbac21			c77d852e53126cc8ebfe1e79d1134e42b54d1aab	gfx5	0	good	no

Chips list

name	tag	type	clock
Speaker	rspeaker	audio
V70	maincpu	cpu	20000000
YMF271	ymf2	audio	16934400
Z80	audiocpu	cpu	4000000

Categories

• Added to Mame in version .119u3
• Mahjong * Mature *
• Tabletop

MAMEinfo

0.119u3 [David Haywood]


< Japan >


Bugs:

- This thing runs WICKED fast. nightsoil (ID 02811)


WIP:

- 0.179: Osso added missing soundlatch to Vs. Janshi Brandnew Stars, this fixed crash when you insert a credit.

- 0.159: Alex Jackson hooked up Player 2 inputs, removed hazeinputs and misc cleanup/modernization.

- 0.154: Vs. Janshi Brandnew Stars regression fix [Miodrag Milanovic].

- 0.153: Converted Vs. Janshi Brandnew Stars to use dual palettes. Note, needed to add PALETTE_FORMAT_XBRG for this game, also READ16_MEMBER(palette_device::read) is necessary here because the ram is installed on every other word AM_DEVREADWRITE16("palette", palette_device, read, write, 0x0000ffff) AM_SHARE("palette") and without the 'read' handler the wrong data gets read back for the RAM checks [David Haywood]. Hooked up sound by borrowing code from Jaleco Mega System 32 and adding the second YMF271. Maybe this bnstars_state should become a derived class of ms32_state, since they seem almost identical except the 2 screens? Made bnstars_state a derivate class of ms32_state and removed some duplicate code [Osso]. Added Z80 (4MHz) CPU2.

- 0.141u4: Breaks some driver entanglements to simplify future driver_device conversion efforts [Atari Ace]: jaleco decryption code is moved to jalcrpt.c.

- 0.141u3: Atari Ace moved code to a new file/include to be referenced in multiple drivers (ms32crpt.c/h).

- 0.128u1: David Haywood fixed screens in Vs. Janshi Brandnew Stars.

- 0.123: David Haywood added clone Vs. Janshi Brandnew Stars (MegaSystem32 Version).

- 0.122u8: Added new gfx2/3 and sound1/2 roms.

- 0.120u2: Sonikos fixed Vs. Janshi Brandnew Stars - Game now playable. Added dipswitches 5x 'P2: x,x,x,x', 'Service Mode ? 1/2', 'Test Mode', 'Free Play', 'First Point', 'Coinage', 'Taisen Only', 'Tumo Pinfu', 'Demo Sounds', 'Difficulty' and 2x 'Unused'.

- 0.119u4: More improvements to Vs. Janshi Brandnew Stars [David Haywood]. Removed Z80 CPU2. Added dipswitches 'MAH0-7', '0-5' and 209x 'Unknown'.

- 7th October 2007: David Haywood - The Single PCB version of Vs. Janshi Brand New Stars is basically a doubled up MegaSystem 32 PCB capable of dual screen output. The entire video section except for the Sprite Chip is doubled (the sprite chip just draws half of spriteram to one screen, and the other half to the other). The bad graphics are due to some of the ROZ layer roms being bad. There are no inputs at the moment, as the input system seems to differ from the MS32 Mahjong boards.

- 0.119u3: David Haywood added 'Vs. Janshi Brandnew Stars' (Jaleco 1997).
