Hanafuda Hana Tengoku (Japan)

Game infos

Sound infos

Driver infos

Inputs infos

Controls infos

type	ways	minimum	maximum	sensitivity	keydelta	reverse
gambling						no
hanafuda						no
mahjong						no

Display infos

type	rotate	flipx	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart
raster	180	no	336	240	60

Dipswitchs

• Coinage
  • 1 Coin/1 Credit
  • 1 Coin/10 Credits
  • 1 Coin/2 Credits
  • 1 Coin/5 Credits
• Credits Limit
  • 1000
  • 2000
  • 3000
  • 5000
• Credits Per Note
  • 10
  • 5
• Demo Sounds
  • Off
  • On
• Double-Up Win Rate
  • 65%
  • 70%
  • 75%
  • 80%
• Flip Screen
  • Off
  • On
• Goko Yaku
  • No
  • Yes
• Guide
  • No
  • Yes
• Hopper Switch
  • Active High
  • Active Low
• In Game Sounds
  • No
  • Yes
• Max Rate
  • 10
  • 5
• Min Rate To Play
  • 1
  • 2
  • 3
  • 5
• Odds For Ameshiko
  • 20
  • 30
  • 40
  • 50
• Odds For Goko
  • 100
  • 200
  • 250
  • 300
• Odds For Shiko
  • 50
  • 60
  • 70
  • 80
• Pay Out Type
  • Credit
  • Hopper
• Payout Rate
  • Bit Low
  • High
  • Higher
  • Highest
  • Low
  • Lower
  • Lowest
  • Medium
• Payout Wave
  • Big
  • Small
• Secret Character
  • No
  • Yes
• Secret Trick
  • No
  • Yes
• Select Stage
  • No
  • Yes
• Service Mode
  • Off
  • On
• Set Clock
  • Off
  • On
• Show Girls
  • No
  • Yes
• Unknown 2-7
  • Off
  • On
• Unknown 2-8
  • Off
  • On
• Unknown 2-9
  • Off
  • On
• Unknown 4-6
  • Off
  • On
• Unknown 4-7
  • Off
  • On
• Unknown 4-8
  • Off
  • On
• Unknown 4-9
  • Off
  • On

Roms list

console	name	bios	size	crc	md5	merge	sha1	region	offset	status	optional
arcade	6501.4b		262144	29a7fc83			5d3cf0a72918e58b5b60f7c978e559c7c1306bce	maincpu	0	good	no
arcade	6502.1a		131072	9276a10a			5a68fff20631a2002509d6cace06b5a9fa0e75d2	gfx2	a0000	good	no
arcade	6503.2a		131072	6ac42304			ce822da6d61e68578c08c9f1d0af1557c64ac5ae	gfx2	80000	good	no
arcade	6504.1b		131072	b2ca9838			7104697802a0466fab40414a467146a224eb6a74	gfx2	60000	good	no
arcade	6505.2b		131072	161058fd			cfc21abdc036e874d34bfa3c60486a5ab87cf9cd	gfx2	40000	good	no
arcade	6506.4c		524288	7de17b26			326667063ab045ac50e850f2f7821a65317879ad	gfx1	0	good	no
arcade	6507.5c		131072	ced3155b			658e3947781f1be2ee87b43952999281c66683a6	gfx2	0	good	no
arcade	6508.6c		131072	ca46ed48			0769ac0b211181b7b57033f09f72828c885186cc	gfx2	20000	good	no
arcade	6509.10b		524288	f8524c28			d50b99664c9f0735838adb55aa7db53e58a43f99	gfx3	0	good	no
arcade	6510.11b		131072	0fdd6edf			c6870ab538987110337e6e154cba98391c68fb98	gfx3	80000	good	no

Chips list

name	tag	type	clock
AY-3-8910A	aysnd	audio	1250000
Speaker	mono	audio
YM2413	ym2413	audio	3579545
Z80	maincpu	cpu	5000000

Categories

• Added to Mame in version .119u4
• Hanafuda
• Tabletop

MAMEinfo

0.119u4 [Luca Elia]


< Japan >


WIP:

- 0.165: Added gambling control.

- 0.156: Osso fixed Hanafuda Hana Tengoku NVRAM.

- 0.148u3: Moved Hanafuda Hana Tengoku (Japan) from Dynax to DonDenLover driver [Miodrag Milanovic].

- 0.119u4: Luca Elia added 'Hanafuda Hana Tengoku (Japan)' (Dynax 1992).

- 6th October 2007: Luca Elia - Here we go again, some new japanese games. We have two hanafuda games, running on the Dynax driver. First up is Hanafuda Hana Tengoku (1992). This one requires a bit more work to be faithfully emulated, since it uses the older Dynax driver blitter with the layers mixer chip usually found on DonDenLover class boards. Next one is Hana wo Yaraneba! (1991). A third hanafuda game, Hanajingi, was also dumped. Alas, I couldn't find any code roms, so it's added as not working. Finally, a Jaleco quiz game, called Hayaoshi Quiz Ouza Ketteisen (1993). Priorities are currently wrong since, as I write, we're missing the dump of a 512 byte prom. This game runs on the Megasys1 driver (which, incidentally, I wrote some 9 years ago!). The later games on this driver use a light form of protection, whereby the inputs are accessed by sending a series of codes to a "device", and reading back the result. The codes are game specific, and prevent any rom swapping. Interestingly, for the first time the dumper identified what appears to be an 8-bit microcontroller, that must be involved. We will need the code from in there, for this and a handful of others games, in order to achieve a faithful emulation. As for this game, it's the first episode of a series. The other two episodes are Hayaoshi Quiz Grand Champion Taikai (already in MAME) and Hayaoshi Quiz Nettou Namahousou (recently dumped). Though they run on a later platform, Jaleco Mega System 32. Thanks to Dyq, Bnathan, Guru / Team Japump, sayu.

- 25th September 2006: Guru - Hana Tengoku arrived a few days ago from Japan with the latest PCB shipment. Thanks to Dyq and BNathan for the funds used to purchase most of the Mahjong games.
