Joy Stand Private

Game infos

Sound infos

Driver infos

Inputs infos

Controls infos

type	ways	minimum	maximum	sensitivity	keydelta	reverse
joy	8					no

Display infos

type	rotate	flipx	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart
raster	0	no	376	240	60	7864320	512	64	440	256	16	256

Configuration

name	tag	mask
Copy Flash Addressing Name Interleaved Value 4096 Default yes Name Sequential Value 0 Default no	COPY	4096
Copy Slot Sense 1 Name Cart Value 0 Default no Name Empty Value 8192 Default yes	COPY	8192
Copy Slot Sense 2 Name Cart Value 0 Default no Name Empty Value 16384 Default yes	COPY	16384
Master Flash Addressing Name Interleaved Value 4096 Default yes Name Sequential Value 0 Default no	MASTER	4096
Master Slot Sense 1 Name Cart Value 0 Default yes Name Empty Value 8192 Default no	MASTER	8192
Master Slot Sense 2 Name Cart Value 0 Default yes Name Empty Value 16384 Default no	MASTER	16384

Roms list

console	name	bios	size	crc	md5	merge	sha1	region	offset	status	optional
arcade	jsp-frm.ic100		279					pld	0	nodump	no
arcade	jsp-map.ic4		279					pld	0	nodump	no
arcade	jsp-sub.1f		279					pld	0	nodump	no
arcade	jsp-xct.ic5		279					pld	0	nodump	no
arcade	jsp.u1		524288	5478b779			5d76645de2833cefb20374480572f06ef496ce30	cart.u1	0	good	no
arcade	jsp.u10		524288	97234b84			06a5dc290e925f5d6a8bade89d970964f32c9945	cart.u10	0	good	no
arcade	jsp.u11		524288	8b138563			8a2092d80d02ac685014540837b9aa38dfe0eb47	cart.u11	0	good	no
arcade	jsp.u12		524288	10001cab			5de49061f9ab81a4dc7e3405132ecec35a63248d	cart.u12	0	good	no
arcade	jsp.u2		524288	adba9522			574e925b35ef3f732989f712caf3f92e16106c22	cart.u2	0	good	no
arcade	jsp.u3		524288	6e293f82			e29099c5337c5e7b4776da01a3bd45141b4900b9	cart.u3	0	good	no
arcade	jsp.u4		524288	4caab540			5cd88dc93c57d3ae9a6b3773222d8f6001b74634	cart.u4	0	good	no
arcade	jsp.u5		524288	2cfee501			2f07179accca0181d20bb0af797194a8ddad4f7a	cart.u5	0	good	no
arcade	jsp.u6		524288	6069d711			e969dcc4b5da6951b4140a78fa7cda350167ca66	cart.u6	0	good	no
arcade	jsp.u7		524288	9f58df4d			e4933087204624c021420bf632a6ddfd7b26179c	cart.u7	0	good	no
arcade	jsp.u8		524288	829ddce6			614ac45d55abe487aaa0e5ca7354926caaa03346	cart.u8	0	good	no
arcade	jsp.u9		524288	e5ee5d8d			ea6ea2fe4fc8b9eaf556453b430c85434ddf1570	cart.u9	0	good	no
arcade	yuvo_jsp001.ic14		524288	bf2b4557			932b96f4b3553e9d52509d678c7c2d4dcfc32cd7	oki	0	good	no
arcade	yuvo_jsp002.ic13		524288	0eb6db96			e5f88f5357709def987f807d1a2d21514b5aa107	oki	80000	good	no
arcade	yuvo_jsp003b.ic3		262144	0c85bc77			ad8ec80b02e82cf43e3f0732cc6e5468c6d21297	maincpu	0	good	no
arcade	yuvo_jsp004b.ic63		262144	333396e5			fc605890676efed476b67abcd1fcb8d509324be2	maincpu	1	good	no
arcade	yuvo_jsp005.2j		524288	98caff66			e201bb0119bc6560b7def40d42d2ef5b788ca3d4	tiles	0	good	no
arcade	yuvo_jsp006.4j		524288	6c9f8048			3fd6effa83b0e429b97d55041697f1b5ee6eafe2	tiles	1	good	no
arcade	yuvo_jsp007a.2g		262144	ccfd5b72			29bf14c888731d63f5d6705d0efb840f1de0fc91	tiles	100000	good	no
arcade	yuvo_jsp008a.4g		262144	fdaf369c			488741b9f2c5ccd27ee1aa5120834ec8b161d6b1	tiles	100001	good	no

Chips list

name	tag	type	clock
M68000	maincpu	cpu	16000000
OKI6295	oki	audio	1000000
Speaker	mono	audio
YM2413	ym2413	audio	3579545

Categories

• Added to Mame in version .165
• Print Club

MAMEinfo

0.165 [Luca Elia, Guru]


< Japan >


NOTE:

- To unlock some hidden items in Test Mode, go in the option menu and move: left, right, left and left.


WIP:

- 0.165: Luca Elia and Guru added 'Joy Stand Private' (Yuvo 1997). Note: This is a sticker machine with camera, printer and light pen.

- 16th August 2015: Luca Elia - Guru dumped this unknown PCBs with a cartridge recently... Alas it's not a game this time, but a sticker-printing machine with screen, joystick and buttons: Yuvo's Joy Stand Private. We have a few of these photo booth boards emulated in MAME already, such as Sega's Print Club series and a couple by Jaleco that I showcased here in the past. See also Wikipedia's Purikura page. Since these titles are not games, their inclusion in MAME has been debated in the past. In the end it was decided that they deserved to be added as coin-operated, video-based machines that you could find in (Japanese) arcades. Also in most cases their hardware was directly derived from arcade game PCBs. Kind of a moot point now that MAME and MESS are merged. In this case the hardware appears to be unique. There are no custom chips on the PCBs and the video rendering is implemented by XC30xx FPGAs. The CPU is a 68000 derivative with on-board peripherals (TMP68301): The system hosts two cartridge slots (master and copy). Near the shell in the photo you can see the dumped cart contains 12 flash chips holding the graphics for the backgrounds and the overlays. These are organized as 16x16 high-color tiles (5 bits per each RGB component and the 16th bit is transparency). The hardware supports both a tilemap of these tiles as well as a frame buffer where the CPU renders the composition of background and overlay chosen by the user. It seems MAME does not support tilemaps with graphics of this depth, so I implemented the rendering myself in the driver. The rest of the graphics (text, girl character) is on the main PCB as EPROMs used by two other tilemaps using more manageable 16-color 8x8 tiles. An OKI chip is used for speech and a Yamaha FM chip plays the background music. This is how it runs under emulation: A couple of tweaks to the flash chips and CPU emulation were necessary to get it to this state, but I did not implement the printer nor the camera communication, so it errors out along the way anyway.

- 16th August 2015: Guru - I dumped a strange and uncommon sticker machine board a while ago and Luca got it working in MAME. Check Luca's site for pics and info.

- 10th October 2005: Guru - Joy Stand Private arrived from Japan. Purchased by the Dumping Project Team.
