Mame game : m4conn4 : Connect 4

Game infos

Description Connect 4

Name m4conn4

Manufacturer Dolbeck Systems

Year 1989?

Runnable yes

System arcade /

Number of players 1P

Added to MAME .108u3

Romset size 32 KB

Romset file 2 files

Romset zip 17 B

Language English

Evaluation 10 to 20 (Horrible)

Genre Electromechanical

Driver infos

Driver status imperfect

Driver emulation good

Driver color good

Driver sound good

Driver graphic imperfect

Driver cocktail

Driver protection

Driver savestate yes

Inputs infos

Input service yes

Input tilt no

Input players 1

Input buttons

Input coins 4

Controls infos

type	ways	minimum	maximum	sensitivity	keydelta	reverse
only_buttons						no

Dipswitchs

DIL101
- Off
- On
DIL102
- Off
- On
DIL103
- Off
- On
DIL104
- Off
- On
DIL105
- Off
- On
DIL106
- Off
- On
DIL107
- Off
- On
DIL108
- Off
- On
DIL201
- Off
- On
DIL202
- Off
- On
DIL203
- Off
- On
DIL204
- Off
- On
DIL205
- Off
- On
DIL206
- Off
- On
DIL207
- Off
- On
DIL208
- Off
- On

Roms list

console	name	bios	size	crc	md5	merge	sha1	region	offset	status	optional
arcade	connect4.p1		16384	b1af50c0			7c9645ea378f0857b849ca24a239d9114f62da7f	maincpu	c000	good	no
arcade	connect4.p2		16384	6090633c			0cd2725a235bf93cfe94f2ca648d5fccb87b8e5c	maincpu	8000	good	no

Chips list

name	tag	type	clock
AY-3-8913A	ay8913	audio	1720000
M6809	maincpu	cpu	1720000
Speaker	rspeaker	audio

0.108u3 [AGEMAME]

WIP:

- 0.143u2: Renamed (connect4) to (m4conn4).

- 0.143: James Wallace used a Dolbeck Systems flyer to correct the colours of the Connect 4 built-in layout.

- 0.133u5: AGEMAME improved the Connect 4 layout.

- 0.128u5: Aaron Giles fixed Connect 4, which crashes if NVRAM file is present.

- 0.123u3: Aaron Giles fixed crash in Connect 4.

- 0.116u4: Improved Connect4 layout [James Wallace, Atari Ace].

- 0.115u3: Luigi30 fixed AY8910_read_port in Connect 4.

- 0.112u2: Added dipswitches 'Invert Alpha?', 'DIL101 - DIL107' and 'DIL201 - DIL208'.

- 10th February 2007: James Wallace - Improved input timing. It appears Connect 4 uses a different sound mapping to regular Barcrest games.

- 0.111u6: James Wallace fixed assertion in MPU4 driver. Fixed the mechanical meter operation, enabling coin entry in Connect 4 - Game now playable.

- 24th January 2007: James Wallace - With thanks to Canonman and Highwayman, I was able to confirm a seemingly ghastly misuse of a PIA is actually on the real hardware. This fixes the meters.

- 0.108u3: El Condor added 'Connect 4' (Dolbeck Systems 198?).

Recommended Games (Connect Four):

Connect 4

4 En Raya

Filetto

Bouncing Balls

Cuatro en Linea

Galaxy Games StarPak 2

Galaxy Games StarPak 3

History

Connect 4 (c) 198? Dolbeck Systems.

Try to beat the machine to 4 in a row for a chance to win cash!

- TECHNICAL -

Designed around Barcrest's MPU4 hardware platform, the game itself is played out on a large light grid on the front of the machine.

Main CPU : Motorola M6809 (@ 1.72 Mhz)
Sound Chips : General Instrument AY8910 (@ 1.72 Mhz)

Palette colors : 16

Players : 1
Buttons : 2

- TRIVIA -

One of the tunes played by the machine is 'We'll Meet Again', by Dame Vera Lynn.

- SCORING -

After winning, you must play the skill stop to actually win the prizes, this can be tricky, and often cheats.
