Magic Train (Ver. 1.31)

Game infos

Parent and clones

Sound infos

Driver infos

Inputs infos

Controls infos

type	ways	minimum	maximum	sensitivity	keydelta	reverse
gambling						no

Display infos

type	rotate	flipx	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart
raster	0	no	512	224	58.727

Dipswitchs

• Coinage
  • 1 Coin / 10 Credits
  • 1 Coin / 100 Credits
  • 1 Coin / 20 Credits
  • 1 Coin / 25 Credits
  • 1 Coin / 50 Credits
  • 1 Coin/1 Credit
  • 1 Coin/2 Credits
  • 1 Coin/5 Credits
• Demo Sounds
  • Off
  • On
• Double Up
  • No
  • Yes
• Double-Up Rate
  • 82%
  • 84%
  • 86%
  • 88%
  • 90%
  • 92%
  • 94%
  • 96%
• Game Limit
  • 10k
  • 20k
  • 30k
  • 60k
• Key Coinage
  • 1 Key / 1 Credits
  • 1 Key / 10 Credits
  • 1 Key / 100 Credits
  • 1 Key / 2 Credits
  • 1 Key / 20 Credits
  • 1 Key / 25 Credits
  • 1 Key / 5 Credits
  • 1 Key / 50 Credits
• Max Bet
  • 20
  • 40
  • 60
  • 80
• Minimum Bet
  • 1
  • 20
  • 40
  • 8
• Unknown
  • Off
  • On
• Win Rate
  • 55%
  • 60%
  • 65%
  • 70%
  • 75%
  • 80%
  • 85%
  • 90%

Roms list

console	name	bios	size	crc	md5	merge	sha1	region	offset	status	optional
arcade	gal16v8d.u18		279					plds	0	nodump	no
arcade	gal16v8d.u19		279					plds	0	nodump	no
arcade	gal16v8d.u26		279					plds	0	nodump	no
arcade	gal16v8d.u31		279					plds	0	nodump	no
arcade	gal16v8d.u6		279					plds	0	nodump	no
arcade	out_1v131.u17		65536	6761be7f			a492f8179d461a454516dde33ff04473d4cfbb27	maincpu	0	good	no
arcade	rom_1.u05		262144	96067e95			bec7dffaf6920ff2bd85a43fb001a997583e25ee	tilemap	3	good	no
arcade	rom_2.u04		262144	a794f287			7b9c0d57224a700f49e55ba5aeb7ed9d35a71e02	tilemap	2	good	no
arcade	rom_3.u03		262144	cef2c079			9ee54a08ef8db90a80a4b3568bb82ce09ee41e65	tilemap	1	good	no
arcade	rom_4.u02		262144	b7e65d04			5eea1b8c1129963b3b83a59410cd0e1de70621e4	tilemap	0	good	no
arcade	rom_5.u27		262144	51cae476			d1da4e5c3d53d18d8b69dfb57796d0ae311d99bf	oki	0	good	no

Chips list

name	tag	type	clock
OKI6295	oki	audio	1058400
Speaker	mono	audio
Z180	maincpu	cpu	1500000

Categories

• Added to Mame in version .139u1
• Casino
• Reels

MAMEinfo

0.139u1 [Roberto Fresca]


WIP:

- 0.151: Angelo Salese fixed exception in clone Magic Train (Clear NVRAM ROM?) shortly after start.

- 0.141u3: Grull Osgo and Roberto Fresca added clone Magic Train (Clear NVRAM ROM?).

- 0.141u2: Grull Osgo, Roberto Fresca, David Haywood and Luca Elia fixed Magic Train - Game now playable. Changed visible area to 512x224. Removed buttons and 2nd coin slot. Added dipswitches 'Coinage', 'Key Coinage', 'Minimum Bet', 'Max Bet', 'Demo Sounds', 'Game Limit', 'Double Up', 'Win Rate', 'Double-Up Rate' and 12x 'Unknown'. Changed description to 'Magic Train (Ver. 1.31)'.

- 0.141u1: Luca Elia moved Magic Train from Subsino to BishouJan driver. Luca Elia fixed access violation before OK. Changed OKI6295 CPU1 clock speed to 1058400 Hz, visible area to 512x240 and 58.727 Hz. Removed YM3812 sound. Added missing 3x buttons and 2nd coin slot. Added 'Alt. Pinout' dipswitch.

- 23rd January 2011: Luca Elia - I've been working on some video slots from the nineties, by Subsino. Here are some almost final screenshots from X-Train (1999) and Magic Train (1996) (which was in MAME as non-working before). The latter needed the decryption devised by Haze to be properly applied, and to be hooked up in the Bishjan driver. In fact, both games run on the same hardware as X-Plan (SS9601 tilemaps, 80188 or Z180 CPU), but make use of a "reel" tilemaps feature that wasn't emulated before. Just a few things remain to be ironed out (like how to switch between "reel" and normal tilemap mode). Also, expect more games on this driver soon... P.S. Rejoice shoot'em up fans, as I also fixed the rogue tiles left on screen in the masterpiece that is X-Plan. Thanks to Grull Osgo, Roberto Fresca, Smitdogg and The Dumping Union.

- 11th January 2011: Smitdogg - I bought a box of random gambling games. First is X-Train. Luca got Magic Train running, X-Train is probably the same hardware.

- 11th January 2011: Smitdogg - Luca got Magic Train running.

- 0.139u4: Roberto Fresca fixed/extended Magic Train technical notes. Eliminated the 3 undumped bipolar PROMs from Magic Train since these are in fact Darlington Arrays instead of bipolar PROMs.

- 0.139u1: Roberto Fresca added 'Magic Train' (Subsino 1997). Since it's driven by a HD647180X0CP6 (Subsino - SS9600) plus SS9601 and SS9602 (for video and I/O respectively), it's possible that needs to be moved to a new driver in a near future. Also added technical notes.
