0.136u2 [Gyrovision, Smitdogg, The Dumping Union]
< Japan >
Bugs:
- Reference pictures from the PCB. Smitdogg (ID 03925)
WIP:
- 0.138u3: Angelo Salese hooked up inputs and Dip-SW for Pinkiri 8.
- 0.138u2: Charles MacDonald dumped the internal Z180 ROM for Pinkiri 8. Improvements to the Pinkiri 8 video emulation [David Haywood, Angelo Salese]. David Haywood deviceized the VDP used by Pinkiri 8 hardware. Added OKI6295 (1056000 Hz) sound. Changed visible area to 512x512.
- 16th June 2010: Angelo Salese - Charles MacDonald extracted the internal ROM on the Eagle 909 HW games (Janshi, Ron Jan and Pinkiri 8). Me and Haze recently did some efforts to emulate this HW, that is a Z180 with a fancy video emulation (that isn't yet fully working). Janshi and Ron Jan have an original thought of the mahjong game, on which you can see what type of tile is with different tilesets for the back.
- 10th June 2010: Charles MacDonald - I trojaned the internal ROM from the CPU module used by "Pinkiri 8". This game uses an external program ROM that is not encrypted (like Lucky Girl was), so I used my 32K ROM emulator to run a small program that relocated to work RAM and copied the internal 16K ROM of the HD647180 CPU to the emulator RAM, and then saved that RAM to disk. The only hard part was probing around the board to find the circuit that generated the memory write strobe, and after that it was pretty easy. UPDATE: Turns out this method worked for three related boards Brian Troha sent earlier, so now those are all dumped too!
- 0.136u2: Gyrovision, Smitdogg and The Dumping Union added 'Pinkiri 8' (
2005). Missing internal ROM, can't do much at the current time.
- 23rd January 2010: Smitdogg - I got Pinkiri 8 really cheap. I wasn't sure what it was, looks to be an old Japanese 8-liner.
