Prop Cycle (Rev. PR2 Ver.A)

Game infos

Sound infos

Driver infos

Inputs infos

Controls infos

type	ways	minimum	maximum	sensitivity	keydelta	reverse
pedal		0	127	100	10	no
stick		0	254	100	10	yes

Display infos

type	rotate	flipx	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart
raster	0	no	640	480	60	24576000	800	0	640	512	0	480

Dipswitchs

• Service Mode
  • Off
  • On
• Unknown
  • Off
  • On

Roms list

console	name	bios	size	crc	md5	merge	sha1	region	offset	status	optional
arcade	c71.bin		8192	47c623ab			e363ac50f5556f83308d4cc191b455e9b62bcfc8	slave	0	good	no
arcade	pr1ccrh.1d		524288	1d68bc31			d534d0daebe7018e83b57cc7919c294ab89bddc8	textilemap	200000	good	no
arcade	pr1ccrl.3d		2097152	e01321fd			5938c6eff8e1b3642728c3be733f567a97cb5aad	textilemap	0	good	no
arcade	pr1cg0.12b		2097152	0a041238			da5688970432f7fe39337ee9fb46ca25a53fdb11	textile	0	good	no
arcade	pr1cg1.10d		2097152	7d09e6a7			892317ee0bd796fa5c70d64912ef2e696792a2d4	textile	200000	good	no
arcade	pr1cg2.12d		2097152	659f006e			23362a922cb1100950181fac4858b953d8fc0794	textile	400000	good	no
arcade	pr1cg3.13d		2097152	d30bffa3			2f05227d91d257db9fa8cae114974de602d98729	textile	600000	good	no
arcade	pr1cg4.14d		2097152	f4636cc9			4e01a476e418e5790878572e83a8a11536ce30ae	textile	800000	good	no
arcade	pr1cg5.16d		2097152	97d333de			e8f8383f49aae834dd8b57231b25899703cef966	textile	a00000	good	no
arcade	pr1cg6.18a		2097152	3e081c03			6ccb162952f6076359b2785b5d800b39a9a3c5ce	textile	c00000	good	no
arcade	pr1cg7.15a		2097152	ec9fc5c8			16de614b26f06bbddae3ab56cebba45efd6fe81b	textile	e00000	good	no
arcade	pr1data.8k		524288	2e5767a4			390bf05c90044d841fe2dd4a427177fa1570b9a6	mcu	0	good	no
arcade	pr1ptrl0.18k		524288	fddb27a2			6e837b45e3f9ed7ca3d1a457d0f0124de5618d1f	pointrom	0	good	no
arcade	pr1ptrl1.16k		524288	6964dd06			f38a550165504693d20892a7dcfaf01db19b04ef	pointrom	80000	good	no
arcade	pr1ptrl2.15k		524288	4d7ed1d4			8f72864a06ff8962e640cb36d062bddf5d110308	pointrom	100000	good	no
arcade	pr1ptrm0.18j		524288	b6f204b7			3b34f240b399b6406faaf338ae0ab536247e64a6	pointrom	180000	good	no
arcade	pr1ptrm1.16j		524288	949588b7			fdaf50ff2496200b9c981efc18b035f3c0a96ace	pointrom	200000	good	no
arcade	pr1ptrm2.15j		524288	dc1cef0a			8cbc02cf73fac3cc110b676d77602ae628385eae	pointrom	280000	good	no
arcade	pr1ptru0.18f		524288	5d66a7c4			c9ed1c18724192d45c1f6b40096f15d02baf2401	pointrom	300000	good	no
arcade	pr1ptru1.16f		524288	e9a3f72b			f967e1adf8eee4fffdf4288d36a93c5bb4f9a126	pointrom	380000	good	no
arcade	pr1ptru2.15f		524288	c346a842			299bc0a30d0e74d8adfa3dc605aebf6439f5bc18	pointrom	400000	good	no
arcade	pr1scg0.12f		2097152	2d09a869			ce8beabaac255e1de29d944c9866022bad713519	sprite	0	good	no
arcade	pr1scg1.10f		2097152	7433c5bd			a8fd4e73de66e3d443c0cb5b5beef8f467014815	sprite	200000	good	no
arcade	pr1wavea.2l		4194304	320f3913			3887b7334ca7762794c14198dd24bab47fcd9505	c352	0	good	no
arcade	pr1waveb.1l		4194304	d91acb26			c2161e2d70e08aed15cbc875ffee685190611daf	c352	800000	good	no
arcade	pr2ver-a.1		1048576	3f58594c			5fdd8c61b47b51088a201799ce0c2f08c32ef852	maincpu	3	good	no
arcade	pr2ver-a.2		1048576	c0da354a			f27a71a62385b842404fcd8ed6513158e3639b8f	maincpu	2	good	no
arcade	pr2ver-a.3		1048576	74bf4b74			02713aa07238cc9e30163ae24d12c034aa972ff3	maincpu	1	good	no
arcade	pr2ver-a.4		1048576	cf4d5638			2ddd00d6ec3b85c234820507650d201e176c94a2	maincpu	0	good	no

Chips list

name	tag	type	clock
C352	c352	audio	24576000
M37710S4	mcu	cpu	16384000
M68EC020	maincpu	cpu	24576000
Speaker	rspeaker	audio
TMS32025	slave	cpu	49152000

Categories

• Added to Mame in version .062
• Hang Gliding
• Sports

MAMEinfo

0.62 [Phil Stroffolino, Guru]


SETUP:

- To calibrate the steering hold down service (9) and tap test (F2). Exit with F2.


WIP:

- 0.148u1: hap improved Prop Cycle pedal. Replaced 8-way Joystick with Pedal and removed button.

- 0.131u3: Changed description to 'Prop Cycle (Rev. PR2 Ver.A)'.

- 0.127u8: R. Belmont fixed Prop Cycle analog input roll over problem.

- 0.108u1: R. Belmont hooked up Prop Cycle fan and lamp to the new output system.

- 0.100u2: R. Belmont replaced old Prop Cycle input hacks with proper analog control. For best results, delete your propcycl.nv file and calibrate (same procedure as Cyber Cycles and Final Lap R) before playing.

- 0.99u7: Fixed sound1 rom address to ($800000).

- 0.86u4: R. Belmont added support for M37710 externally-pulsed timers, Prop Cycle uses this to read the pedals.

- 0.86u1: Phil Stroffolino added preliminary dynamic lighting for system22 (rarely actually used - see Prop Cycle turning score/time digits).

- 25th August 2004: R. Belmont - Got the M37710 talking to the 68020 in the Super System 22 games, so e.g. Prop Cycle now has music and sound effects. Now working out how the MCU reads the controls to eliminate more HLE hacks...

- 0.85u2: Added M37710 (16Mhz) CPU4 and C352 stereo sound. Changed region cpu4 to user4 and user2 to sound1.

- 0.81u8: Phil Stroffolino fixed Namco System 22 driver and TMS32025 CPU. The slave DSP's in-game graphics processing and "custom render devices" are currently simulated, which works only for Prop Cycle. Most self tests are working now in Prop Cycle and Ridge Racer. Added 2x TMS32025 (48MHz) CPUs and changed region cpu2 to cpu4.

- 0.75: Phil Stroffolino fixed display list processing (affects Prop Cycle ending). Changed description to 'Prop Cycle (Rev PR2 Ver.A)'.

- 0.71u2: Huge improvements in Prop Cycle [Phil Stroffolino]: Pulled out matrix3d to its own module. Near plane clipping. Perspective correct textures. Preliminary lighting (all or nothing). Gamma correction. Preliminary fader support. Per polygon and per object depth bias Sprite-polygon priority. Two-sided polygon flag. Tile flip attributes. Tilemap color bank. Improved steering responsiveness. Camera zoom and pan feature. Fixes to display list parsing. Corrected rotation mappings for System22/21. Changed description to 'Prop Cycle (Rev. PR2 Ver.A)'.

- 0.70u4: Added cpu2 rom (pr1data.8k - 512k SS22-BIOS ver1.41) and user2 roms ($0, 400000 - 4MB sound samples).

- 0.63: Added 8-way Joystick and 1x button.

- 7th December 2002: smf fixed the Prop Cycle inputs so that they can be re-mapped.

- 0.62: Phil Stroffolino added 'Prop Cycle' (Namco 1996). TODO: Hook up real analog controls for steering yoke. Need new input port type for pedal. Map motor output (fan, blows air towards player when flying fast). Map lamp output (start button lights can light up). Sound (WAVE roms aren't dumped).

- 12th July 2003: Phil Stroffolino sent in a major improvement to the Namco Super System 22 driver, fixing a lot of the graphics in Prop Cycle.

- 11th June 2002: Guru - Finally dumped Prop Cycle and Phil Stroffolino presents an early WIP screenshot of it.

- 4th February 2002: Guru - A Prop Cycle (Namco 1996, Super System22) PCB arrived from Phil Stroffolino.


LEVELS: 4
