Puzzle Star (ver. 100MG)

  1. Game infos
  2. Sound
  3. Driver
  4. Inputs
  5. Controls
  6. Display
  7. Configurations
  8. Dipswitchs
  9. Roms list
  10. BIOS set
  11. Chips list
  12. Categories
  13. MAMEinfo
  14. History
  15. High scores
Download puzlstar.zip (13 MB)
Snapshot

Game infos

Description Puzzle Star (ver. 100MG)
Name puzlstar
Manufacturer IGS
Year 1999
Runnable yes
System arcade /
Number of players ???
Added to MAME .084u5
Romset size 13 MB
Romset file 6 files
Romset zip 5 B
Language English
Genre Puzzle

Sound infos

Sound_channels 1

Driver infos

Driver status preliminary
Driver emulation preliminary
Driver color good
Driver sound imperfect
Driver graphic good
Driver cocktail
Driver protection preliminary
Driver savestate yes

Inputs infos

Input service no
Input tilt no
Input players 4
Input buttons
Input coins 4

Controls infos

type ways minimum maximum sensitivity keydelta reverse
joy 8 no

Display infos

type rotate flipx width height refresh pixclock htotal hbend hbstart vtotal vbend vbstart
raster 0 no 448 224 59.17

Configuration

name tag mask
Region
Name China
Value 0
Default no
Name Hong Kong
Value 4
Default no
Name Japan (Alta license)
Value 2
Default no
Name Korea
Value 3
Default no
Name Taiwan
Value 1
Default no
Name World
Value 5
Default yes

Region
 15

Dipswitchs

Roms list

console name bios size crc md5 merge sha1 region offset status optional
arcade a0800.u1 4194304 e1e6ec40 390432431f144ef63424a426582b311765a61771 sprcol 0 good no
arcade b0800.u3 2097152 52e7bef5 a678251b7e46a1016d0afc1d8d5c9928008ad5b1 sprmask 0 good no
arcade m0800.u2 4194304 e1a46541 6fe9de5700d8638374734d80551dcedb62975140 ics 400000 good no
arcade pgm_m01s.rom 2097152 45ae7159 pgm_m01s.rom d3ed3ff3464557fd0df6b069b2e431528b0ebfa8 ics 0 good no
arcade pgm_p01s.u20 v1 131072 e42b166e pgm_p01s.u20 2a9df9ec746b14b74fae48b1a438da14973702ea maincpu 0 good no
arcade pgm_p02s.u20 v2 131072 78c15fa2 pgm_p02s.u20 885a6558e022602cc6f482ac9667ba9f61e75092 maincpu 0 good no
arcade pgm_t01s.rom 2097152 1a7123a0 pgm_t01s.rom cc567f577bfbf45427b54d6695b11b74f2578af3 tiles 0 good no
arcade puzlstar_igs027a.bin 16384 prot 0 nodump no
arcade t0800.u5 2097152 f9d84e59 80ec77025ac5bf355b1a60f2a678dd4c56071f6b tiles 180000 good no
arcade v100mg.u1 524288 5788b77d 7770aae6e686da92b2623c977d1bc8f019f48267 maincpu 100000 good no
arcade v100mg.u2 524288 4c79d979 3b92052a35994f2b3dd164930154184c45d5e2d0 maincpu 100001 good no

BIOS set

name description default
v1 PGM Bios V1 yes
v2 PGM Bios V2 yes

Chips list

name tag type clock
ARM7 prot cpu 20000000
ICS2115 ics audio
M68000 maincpu cpu 20000000
Speaker mono audio
Z80 soundcpu cpu 8467200

Categories

MAMEinfo

0.84u5 [David Haywood]


WIP:

- 0.147u3: Fixed maincpu rom loading.

- 0.145u5: Changed VSync to 59.17 Hz.

- 0.130u3: Changed description to 'Puzzle Star (ver. 100MG)'.

- 0.130u2: Added ARM7 (20MHz) CPU3.

- 0.126u5: Guru added README for Puzzle Star.

- 0.105u3: XingXing simulated the protection in Puzzle Star - Game now playable.

- 0.84u5: David Haywood added 'Puzzle Star' (IGS 1999).

- 22nd April 2004: David Haywood - ElSemi passed along some code to me from a contributor in China known as 'XingXing'. The code was to simulate the protection in the PGM game 'Puzzle Star', another one of the Mysterious PGM games which never appeared on the IGS site when most of the other titles were up. It's a puzzle game, very similar to Mang-Chi which was emulated a few days ago but with some extra twists (involving the stars, combos and 'promotions'). There may be one or two problems with the simulation, but for the most part it seems to work correctly.

- 25th July 2004: David Haywood added Puzzle Star to the PGM driver but it also does not work because of protection.

- 30th July 2004: A Puzzle Star PGM cart arrived, purchased by Randy on EBay. I've dumped it, but it will require trojaning to get the emulation working. We're working on it.


Other Emulators:

* FB Alpha

* Nebula

History


IGS PGM cart. published 20 years ago:

Puzzle Star (c) 1999 IGS Company, Limited. [International Game System].

- TECHNICAL -

IGS PGM hardware

Main CPU : Motorola 68000 (@ 20 Mhz)
Sound CPU : Zilog Z80 (@ 8.468 Mhz)
Sound Chips : ICS2115 (@ 8.468 Mhz)

Players : 4
Control : 8-way joystick
Buttons : 4

- TRIVIA -

Puzzle Star was released in September 20, 1999.

- CONTRIBUTE -

Edit this entry: https://www.arcade-history.com/?&page=detail&id=3519&o=2

High scores

MAMESCORE records : 02/04/2017 13:01

furohon________________________52.100
hulkiii________________________50.600
