Trail Blazer

Game infos

Sound infos

Driver infos

Inputs infos

Controls infos

type	ways	minimum	maximum	sensitivity	keydelta	reverse
only_buttons						no

Display infos

type	rotate	flipx	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart
raster	0	no	368	256	60

Dipswitchs

• 1
  • Off
  • On
• 4
  • Off
  • On
• NVRAM Reset?
  • Off
  • On
• PIA0.A
  • Off
  • On
• PIA0.B
  • Off
  • On
• PIA1.B
  • Off
  • On
• PIA2.B
  • Off
  • On
• Service Mode
  • Off
  • On
• Show Refill
  • Off
  • On
• Show Stats
  • Off
  • On
• Tests
  • Off
  • On
• Unknown
  • Off
  • On

Roms list

console	name	bios	size	crc	md5	merge	sha1	region	offset	status	optional
arcade	1-2.45		8192	b4a807b1			f00a4790adb0c25917a0dc8c98c9b65526304fd3	gfx1	0	good	no
arcade	1-4.09		16384	7c34749c			3847188a734b32979f376f51f74dff050b610dfb	maincpu	0	good	no
arcade	2-2.41		8192	756dd230			6d6f440bf1f48cc33d5e46cfc645809d5f8b1f3a	gfx1	2000	good	no
arcade	2-4.06		16384	81a9809b			4d2bfd5223713a9e2e15130a3176118d400ee63e	maincpu	4000	good	no
arcade	questions.bin		655360					user1	0	nodump	no

Chips list

name	tag	type	clock
AY-3-8910A	aysnd	audio	1750000
Speaker	mono	audio
Z80	maincpu	cpu	3500000

Categories

• Added to Mame in version .100u1
• English
• Quiz

MAMEinfo

0.100u1 [Pierpaolo Prazzoli]


WIP:

- 0.129u6: Added dipswitches 'PIA0.A', 'PIA0.B', 'PIA1.B', 'PIA2.B' and 14x 'Unknown' dipswitches.

- 8th January 2009: David Haywood - I've been working with Roberto Fresca on some drivers lately. One that came to our attention was the 'Coinmaster' one, due to a recent dump of a Poker game running on that hardware. I was asked if I could take a look at the tile banking, and try to locate the palette, which was proving to be difficult to find. After some educated guesswork I ended up with the following (see screenshots). Turns out the game has a 1 bit per colour, 4 colours per tile palette stored with the tile data in ram, rather than a global palette which any tile can access. There are still a few things to be figured out, such as if it has brightness control on the colours (which would allow more colours) and if the extra ram that Super Nudge 2 and the Poker game have expand the palette in any way.

- 0.100u1: Pierpaolo Prazzoli added 'Trail Blazer' (Coinmaster 1987).

- 9th September 2005: Pierpaolo Prazzoli - I started to re-look at Coinmaster's trivia games: Quiz Master (1985), Trail Blazer (1987) and Super Nudge 2 (1989). They're really weird. They use a 46 x 64 tilemap with videoram starting at offset $240 and using the previous offsets as main ram. Also tile banking is strange. They use an attribute ram for every banking address bit they need (so in games with $400 tiles, they have 2 attributes rams with all the other 14 bits used and still unknown). I don't know if they have a hard-coded palette or if they use a strange paletteram format.
